DESCRIPTION In line with the advancement of electronic technology towards the miniaturization of large-scale integrated
circuits. It inevitably increases the risk of electronic
components or systems being damaged by power
surges caused by lightning or power failure.
Power lines are one of the most common channels for surges to pass through. and cause damage to sensitive
electronic systems and operational disruptions.
|
| ข้อมูล |
น้ำหนัก
บาร์โค้ด
ลงสินค้า
อัพเดทล่าสุด
|
| รายละเอียดสินค้า |
Design & Structural : Single Stage High Energy Handling Design incorporated with removable / replaceable TVSS module and Remote Alarm circuit. 10/100/1000/10G Base-T RJ45 (Input, Output)
Electrical System :
Nom. Line Voltage (Un) : 230 Vrms, 50-60Hz Max. Line Voltage (Uc) : 275 Vrms, 50-60Hz Rate Current : unlimited
Reference Standard : IEC 61641-1:2002
IEC 61643-1:2005
ITU-T Rec. K.12
DIN VDE 0675
UL-1449 (2nd edition 1996)
ANSI/IEEE C62.41-1991 Category IEC/EN/VDE : Class II / Type2 / C Protection Config :
Installation : Shunt
Protective Device : Single MOV
Responstime : <25 nanosec.
Recommended back-up fuse : 125A gL
TOVs Surge Protection: (TOVs) > 800 mA, 50 Hz in 5 Sec (pin 1-2, 3-6) > 14 Volt
Surge Rating :
Nominal discharge surge current In(8/20)∝s : 20kA Max. discharge surge current Imax(8/20)∝s : 40kA Max. operational Voltage 6Vdc (Pin 1-2, 3-6) & 60 Vdc (pin 4-5, 7-8)
FEATURES
> High Surge Current Rating
> Shunt Configuration Design
> Fast Response time
> Normal mode protection
> Low let through voltage
> Terminal Interface for hard wire
> Easy to Installation
> Remote Alarm
> DIN rail Mounting
Transient Surge Current : (Transient) at1.5 kA 8/20Sec
![]() |
